Briggs & Stratton SimpliPHI® 6.6 Battery Installation in New Jersey
Power your home or business with the Briggs & Stratton SimpliPHI® 6.6 Battery —
a flexible, scalable energy storage solution designed to work as part of a complete
Energy Ecosystem. Whether you want battery backup during outages, smarter
energy management, or solar + storage integration, the SimpliPHI 6.6 helps deliver reliable,
efficient power when you need it most.
Smarter backup power, greater flexibility, and more control over your energy future.
What Is the SimpliPHI® 6.6 Battery?
The SimpliPHI® 6.6 Battery from Briggs & Stratton is a compact, high-performance
energy storage solution built for modern residential energy systems. As part of the
Energy Ecosystem, it stores usable energy for later use, helps provide backup power
during outages, supports solar self-consumption, and gives property owners greater
flexibility in how they manage electricity.
This battery is designed to integrate with leading inverter platforms and can be used
in a variety of applications including backup power, time-of-use savings, solar + storage,
and off-grid or hybrid-style systems.
scalable, and strategically managed energy system.
Built for the Energy Ecosystem
The SimpliPHI® 6.6 Battery works seamlessly within a complete energy strategy:
- Store solar energy for use later
- Support your home during outages
- Reduce high peak energy usage
- Integrate with leading inverters
- Expand capacity as your needs grow
Key Benefits
Reliable Backup Power
Keep essential systems running when utility power goes down by storing energy for
later use and supporting your backup power strategy.
Solar + Storage Ready
Pair battery storage with solar panels to maximize self-consumption and make better
use of the power your system generates.
Strategic Energy Use
Manage energy usage more intelligently and help reduce exposure to high peak energy costs.
Why Homeowners Choose the SimpliPHI® 6.6
- Faster Installations: RapidStak connector combines communications and power in one connection. Assemble a stack of 3 in under 5 minutes.
- Wire and Hassle Free: No wires, no DIP switches, and fewer tools, accessories, and complications.
- Scalable for Any Application: Each battery delivers 6.65 kWh. Stack 3 for 19.95 kWh in a compact footprint, or scale up to 6 stacks for 119.7 kWh of energy.
- Versatile Installation Options: Indoor or outdoor applications with IP65-rated installation capability. Ground or wall mount options available.
- Choose Your Inverter: Designed to integrate with leading inverters for flexibility and faster commissioning.
- Designed for Versatility: Use for backup power, time-of-use savings, solar + storage, or off-grid power strategies.
- Advanced Safety Standards: Validated to rigorous safety and testing standards.
- Safer Battery Chemistry: Lithium ferro phosphate (LFP) chemistry with a strong reputation for safety and performance.
Energy Ecosystem Applications
Battery Backup
Keep lights, refrigeration, communications, and other important systems powered
when the grid goes down.
Time-of-Use Savings
Store power for use during higher-rate periods and manage energy more strategically.
Solar + Storage Integration
Use the battery as part of a complete solar and inverter system to improve
efficiency and flexibility.
Specifications
| Specification | SimpliPHI® 6.6 Battery |
|---|---|
| Maximum per Stack | 3 |
| Maximum per System | 18 |
| DC Voltages – Nominal | 51.2 VDC |
| Amp-Hours | 130 |
| Rated kWh Capacity | 6,656 |
| MAX Surge Discharge Rate (10 Minutes) | 240 ADC, 2 sec / 300 ADC, 1 sec |
| MAX Continuous Discharge Rate | 130 ADC |
| MAX Continuous Charge Rate | 100 ADC |
| DC Voltage Range | 44.8 – 56.8 VDC |
| Charging Temperature | -10°C ~ 50°C |
| Discharge Temperature | -20°C ~ 55°C |
| Operating Humidity | 0% – 95% RH |
| Storage Temperature | -20°C ~ 55°C for 1 month / -20°C ~ 45°C for 6 months |
| Storage Humidity | 0% – 95% RH |
| Enclosure Material | Powder-coated Steel |
| Self-Discharge Rate | <.03 %/month (shutdown/off) |
| Cycle Life | 4500 Cycles @ 0.75C charge/discharge rate (@ 100% DoD) |
| IP Rating | IP 20 (IP 65 when installed) |
| Weight | 125 lbs (56.7 kg) |
| Dimensions (W x H x D) |
Width – 28.6 in. (725.0 mm) Depth – 6.7 in. (170.0 mm) Height without Tabs – 17.3 in. (440.0 mm) Height with Tabs – 18.9 in. (479.2 mm) |
| Wall Mount Dimensions | 28.6 x 60.4 x 6.7 in. (Full Stack) |
| Efficiency Rating | ≥96% |
| Altitude | ≤3000M |
| Corrosion Resistance Rating | 240H |
| Salt-Fog Rating | 240H |
| Communications | CAN, RS485 – Compatible with leading inverters |
| Certifications | UL9540, UL 9540A, UL1973, UL 1998 + 991, UN 38.3, UN 3480, IEC62619 |
Scalable Storage for Real-World Energy Needs
The SimpliPHI® 6.6 Battery is designed for flexibility. One battery can support smaller
storage goals, while stacked configurations can provide nearly 20 kWh in a compact footprint.
Larger systems can be expanded even further for homes or applications that require more stored energy.
This makes the SimpliPHI® 6.6 an ideal fit for homeowners who want to start with backup power
today and build toward a more complete Energy Ecosystem over time.
Ready to Add Battery Storage to Your Energy Ecosystem?
Innovative Electric can help you design and install a complete battery storage solution
using the Briggs & Stratton SimpliPHI® 6.6 as part of a larger Energy Ecosystem.
Call: 908-879-7078
Email: sales@innoelec.net
Contact us today to discuss battery backup, solar + storage, generator integration,
and complete Energy Ecosystem installation in New Jersey.
